EVM437x

TI AM 437x, ARM Cortex-A9 @ 300M-1GHz

Consultation & Ordering

EVM437x is a multifunctional development kit based on SOM437x,which perfectly supports Linux4.4.19 operating system .EVM437x is suitable for the rapid development in different industries.SOM437x is mounted onto EVM437x carrier board through stamp hole.The carrier board has extended a rich set of interfaces including HDMI,LVDS,Touch Screen,Camera,etc.
  • Hardware
  • Contents
  • Software
  • Document
  • Application

Introduction

EMA SOM437x product line spans TI AM4372/4376/4377/4378/4379.
SOM437x has advantages in up to 1GHz of processing power as well as 3D graphics acceleration for rich graphical user interfaces .The 220-pin SOM has rich interfaces such as Ethernet,LCD,USB,UART,etc.SOM437x is featured in supporting multiple industrial communication protocols.It also has large storage with 256M-1G Nand Flash or 8G-64G eMMC.

Carrier Board Features

  • WIFI+BT GPS+BD

  • 1x RS485 2x RS232 4x UART TTL

  • 1x RJ45(10/100/1000M Ethernet)

  • 1x HDMI 1x LVDS

  • 1x Touch Screen

  • 2x USB 2.0 Host 1x USB OTG

  • 8x ADC, 1x SATA, 1x ZIGBEE, 1x CAN,Mini-PCIe

  • SD/SIM card slot

  • 1x Camera interface(up to 1300M pixel)

Consultation & Ordering

FAE

Sales

Contacts

Mr. Ken

Miss Jessy

Call phone

(+86) 159 1576 8027

(+86) 131 1959 1334

E-mail

support@ema-tech.com

sales@ema-tech.com

Message Board
Title:
Message:
E-mail:
Verification:
EMA SOM437x is mounted onto EVM437x carrier board through stamp hole.The carrier board has extended a rich set of interfaces including HDMI,LVDS,Touch Screen,Camera,etc.

Kit Contents

Optional Contents

SOM4379-A109D-A1-C

WIFI+BT module

EVM437x carrier board

GPS+BD module

Power line

ZIGBEE module

9 pin serial cable

7 inches LCD+Capacitive touch screen

USB-OTG data cable

10.4 inches LCD+Resistive touch screen

Ethernet cable

15 inches LCD+Resistive touch screen

TTL to 232

Emluator

SD card(8G)

USB to Serial cable

Development File

Warranty Card

Software Parametrics:

Linux

Boot & Download

Version

u-boot 2016.05

Boot Mode

Boots from eMMC/SD.

Boot Speed

Supports Boot Speed Optimization.

Splash Screen

Supports Splash Screen Customization.

Download Method

Downloads from Internet and Serial Port.

Kernel

Kernel Version

Linux 4.4.41

File System Format

EXT3/EXT4/NFS/JFFS2/UBIFS

Device Driver

Provides all peripheral drivers.

File System

Can customize File System based on your requirements.

Graphical Interfaces

QT5.7

Provides perfect QT development resources.

Android

Version

Android 6.0

Device Drive

Provides all peripheral drivers.

EMA-IO

Supports UART, CAN, GPIO when android system device access.

EMA-Launcher

Supports Boot Animation Customization.

Can start specified application automatically when system boot.

Supports program management including installation / uninstall / upgrade / start and other functions.

Supports Internet management.

ROM Customization

Supports ROOT.

Supports virtual keys hidden.

Supports Status Bar hidden.

Supports System notification Block.

Supports Lock Screen hidden.

Can integrate third-party applications.

Application Areas

SOM437X can be used for medical and industrial areas of embedded application, including networked industrial drive controller, consumer medical apparatus and instruments, HMI industrial man-machine interface, navigation equipment, barcode scanners, portable data terminal, test and measurement, industrial automation and other fields.
  • Networked Industrial Drive Controller
  • Consumer Medical Instruments
  • Human-Machine-Interface
  • Navigation Equipment
  • Barcode Scanner
  • Portable Data Terminal
  • Test Measurement
  • Industrial Automation
